Autex Cube Panel 6mm acoustic panels reject the restraints of traditional acoustic panels, offering versatility and creative freedom in place of dull conventionality. A blank canvas for customisation, Cube panels can be cut, moulded, printed, pressed, and grooved to create high-performance acoustic features for any interior space. Made from 100% polyester fibre, Cube realises innovative design concepts without pomp or circumstance.

Autex Cube Panel 6mm is specially designed to reduce noise and control reverberated (echo) noise in building interiors. Autex Cube Panel 6mm offers an NRC rating of 0.45 and is ideal to be installed on walls, however, it can be used for many other applications including acoustic pinboards. Autex Cube is to be installed indoors only, Autex Cube Panel 6mm is easy to custom cut using a track saw with an aluminum (close tooth) blade. For best results, we reckoned using the TensorGrip F31 adhesive.

Discover the limitless design flexibility of Autex Cube Panel 6mm is a lightweight and semi-rigid panel that has sound-absorbing properties. Designed with solid color throughout, Autex Quietspace Cube Panel has the potential to be used in a large array of spatial design and interior solutions.

More than just a traditional interior acoustic panel, 6mm Cube Panel can be employed as a base material for creative solutions where design and aesthetics are important. Autex Cube Panel 6mm Cube panels are available in 12 mm and 24 mm thicknesses for application flexibility, and don’t require edging or capping.

Customise Autex Cube Panel 6mm. As creators and innovators, we understand your pursuit of the bold and unusual, the rare and exceptional—the brave, colour-outside-the-lines ideas. Every space you design is unique, therefore, every element—from floor to ceiling—should be tailored to fit. Our customisation tools offer unique avenues for creative expression to help you achieve your vision—all that’s left to explore are the boundaries of your imagination. Our customisation capabilities for the Autex Cube Panel 6mm include Print, EtchTM, Groove, Precision Cut, Mould and Press, and
Peel ‘n’ Stick.

Autex Cube Panel 6mm Acoustic Performance

Autex Cube Panel 6mm is specifically designed to reduce and control reverberated and echo noise in building interiors.

Absorption Coefficient According to ISO 354 University of Auckland Testing Service

  • Cube (12mm) – Test No. T0712-3
  • Cube (12mm with 25 mm air gap) – Test No. T0712-6
  • Cube (24mm) – Test No. T1961-1
  • Cube (24mm with 25 mm air gap) – Test No. T1326-2

Autex Cube Panel 6mm Applications

  • Decorative and functional acoustic wall covering for education, retail and commercial interiors
  • Media for creative solutions
  • Acoustic pinboard surface for education and commercial sectors
  • Modular room divider for display, privacy and sound absorption

Terms of Sale

  1. I understand that there are no refunds or exchanges for this product.
  2. I accept the manufacturing and freight lead time when placing an order for this product.
  3. I understand that the colours on my screen may not match the actual product.
  4. I understand this product may have a MOQ and will order no less than the MOQ.

Autex Cube Panel 6mm Colour Options

Cube Acros
Acros
Cube Beehive
Beehive
Cube Canyon
Canyon
Cube Caspian
Caspian
Cube Cavalier
Cavalier
Cube Empire
Empire
Cube Falling Water
Falling Water
Cube Flatiron
Flatiron
Cube Gherkin
Gherkin
Cube Herald
Herald
Cube Highland
Highland
Cube Muralla
Muralla
Cube Opera
Opera
Cube Parthenon
Parthenon
Cube Pavilion
Pavilion
Cube Petronas
Petronas
Cube Pinnacle
Pinnacle
Cube Sargazo
Sargazo
Cube Savoye
Savoye

Disclaimer: The colours displayed on this website have been provided by the manufacturer for reference purposes only. Please note that these colours are intended as a guide and may not accurately represent the true colour. For a more precise depiction of colour, we recommend requesting a colour swatch.

Specifications

SKU AUTEX-CUBE-6MM Categories ,
  • Wall) treatment shall be CubeTM from thermally bonded high density polyester containing not less than 60% recycled material as manufactured by Autex www.autexglobal.com
  • Panel 1220 x 2440 x (_)mm (nom.) depth, colour (_), sound absorption 12 mm: Class D, NRC 0.45 – with 24 mm air gap: Class C, NRC 0.70. 24 mm: Class D, NRC 0.70– with 24 mm air gap: Class C, NRC 0.80. Fire rating ASTM E-84-15a: Class A, FS:0 – SD:45, ISO 9705: Classification: Group 1-S, AS ISO 9705 – 2003 Classification: Group 1, BS EN 13501-1:2018: B – s2, d0.
  • If Cube is to be specified for use other than as a wallcovering, please seek guidance from your Ordio Acoustics sales consultant.

Product Documentation

Download Product Documentation

Ordering

  • Product name: CubeTM
  • Composition: 100% polyester fibre
  • Panel dimension: 1220 mm x 2440 mm
  • Tolerance: (+ 5 mm) x (+ 10 mm)
  • Thickness: 12 mm 24 mm
  • Tolerance: (+/- 6%) (+/- 6%)
  • Thermal performance: Cube 12 mm; R0.41 (@15°C) / Cube 24 mm; R0.82 (@15°C)
  • Installation: Install as per Autex Acoustics recommendations. Install instructions are included in each pack or available on the website. If Cube is to be specified for use other than as a wallcovering, please seek guidance from your Ordio Acoustics sales consultant.
Lead Time: 7 – 10 Days
Quantity: MOQ: 12x Panels

$149 Inc GST

  • Colour Options *

  • Panel Size *

Product total

Options total

Grand total
