ATC SCM12i Pro Studio Monitor

The ATC SCM12i Pro Studio Monitor is a compact 2-way passive speaker, perfect for recording and broadcast studios. Its versatility suits surround/multi-channel setups like Dolby Atmos, while easy installation and ATC’s advanced technology ensure consistent performance.

ATC SCM12i Pro Studio Monitor

Introducing the ATC SCM12i Pro Studio Monitor, a compact 2-way passive monitor meticulously engineered for seamless integration into recording, post-production, broadcast, and film studios. Its small footprint belies its exceptional performance, rendering it a standout choice for surround/multi-channel recording, mixing, and immersive audio applications like Dolby Atmos, DTS:X, and Auro 3D. Streamlining installation, the cabinet is equipped with mounting points compatible with popular wall and ceiling brackets.

Embodying ATC’s renowned philosophy, the SCM12i draws from the same driver components and technology found in their larger 2 and 3-way active monitor loudspeakers, ensuring exceptional consistency across the entire product range. Elevate your studio experience with the ATC SCM12i Pro Studio Monitor – where compact form meets uncompromising performance.

Features

  • Wide bandwidth & high SPL capability
  • Neutral timbre & low distortion for low listener fatigue
  • 150mm / 6” ATC CLD Bass Driver
  • 25mm / 1” ATC Dual-Suspension HF Driver
  • Cabinet mounting points for wall/ceiling mount
  • 6 year warranty

Specifications

  • Drivers:
    • HF ATC 1˝/25mm dual suspension Soft Dome (SH25-76 6 Ohm)
    • LF ATC 6˝/150mm Constrained Layer Damping (CLD) (SB45-150CLD 8 Ohm)
  • Amplitude Linearity: 80Hz – 16kHz (+/-2dB)
  • Cut Off Frequencies: 56Hz – 22kHz (-6dB freestanding)
  • Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
  • Maximum Continuous SPL: 108dB (per pair @ 1m)
  • Crossover Frequency: 2.2kHz
  • Recommended Power Amplifier: 75 to 300 Watts
  • Nominal Impedance: 8 Ohm
  • Connectors: Binding Posts/4mm Plugs, biwire
  • Cabinet Dimensions (HxWxD): 400x238x235mm (eye bolt adds 40mm to the depth)
  • Weight (Per Cabinet): SCM12 Pro 11kg, SCM12i Pro 15kg

User Manual

Download the User Manual in PDF format.

Ordering

SKU SCM12i Categories , Tag

$3,899 Inc GST
